Get started.

# 1. Install uhubctl if needed: Debian, Ubuntu, or Raspberry Pi OS
sudo apt install uhubctl

# macOS with Homebrew
brew install uhubctl

# 2. Discover the target module
sudo uhubctl
Current status for hub 1-2 [1a86:8094 Peachoid Labs PL-USB20-SW1 123456, USB 2.00, 1 ports, ppps]

# 3. Target module serial number
SERIAL="123456"

# 4. Resolve hub location by serial
HUB_LOCATION="$(
  sudo uhubctl | awk -v serial="$SERIAL" '
    /^Current status for hub / && index($0, serial) {
      sub(/^Current status for hub /, "")
      sub(/ .*/, "")
      print
      exit
    }
  '
)"

# 5. Stop if the serial number was not found
[ -n "$HUB_LOCATION" ] || { echo "Module serial not found: $SERIAL"; exit 1; }

# 6. Switch the module's single controlled port
sudo uhubctl -l "$HUB_LOCATION" -p 1 -a off
sudo uhubctl -l "$HUB_LOCATION" -p 1 -a on

# 7. Power cycle: turn off for 3 seconds, then back on
sudo uhubctl -l "$HUB_LOCATION" -p 1 -a cycle -d 3

# 1. Install the filter driver once, then restart Windows
.\vhfilter.exe --install-filter

# 2. Discover the target module
.\vhfilter.exe --list-hubs
The following hubs are attached that support Per-Port-Power-Switching:
USB\VID_1A86&PID_8094\MSFT20123456       has  1 ports   is USB 2
                            └─ module serial: 123456

# 3. Switch the module's single controlled port
.\vhfilter.exe --switch-port 1 off "USB\VID_1A86&PID_8094\MSFT20123456"
.\vhfilter.exe --switch-port 1 on "USB\VID_1A86&PID_8094\MSFT20123456"

# 4. Power cycle: turn off for 3 seconds, then back on
.\vhfilter.exe --switch-port 1 off "USB\VID_1A86&PID_8094\MSFT20123456"; Start-Sleep -Seconds 3; .\vhfilter.exe --switch-port 1 on "USB\VID_1A86&PID_8094\MSFT20123456"

Identification-only workflows

Persistent USB identity

Even when power cycling is not needed, the module serial provides a persistent identity for the USB connection, including when a device’s COM or tty path changes—for example, from COM17 to COM23 on Windows. This is also useful for devices that cannot be uniquely identified, including multiple identical devices and devices without serial numbers.

Verify module-to-device mapping

Linux

This example uses uhubctl to resolve each module's current hub location, then follows the module's single downstream port to the mounted drive.

# Record module serials with attached drives.
# Write a distinct marker file to verify each mapping.
# No power cycle required.
MODULE_A_SERIAL="123456"
MODULE_B_SERIAL="123457"

module_mount_by_serial() {
  local serial="$1" hub_location usb_path block_device mount_point

  hub_location="$(
    sudo uhubctl | awk -v serial="$serial" '
      /^Current status for hub / && index($0, serial) {
        sub(/^Current status for hub /, "")
        sub(/ .*/, "")
        print
        exit
      }
    '
  )"
  [ -n "$hub_location" ] || { echo "Module serial not found: $serial" >&2; return 1; }

  usb_path="/sys/bus/usb/devices/${hub_location}.1"
  [ -d "$usb_path" ] || { echo "Downstream port not found for $serial" >&2; return 1; }

  while IFS= read -r block_device; do
    mount_point="$(findmnt -rn -S "/dev/$block_device" -o TARGET | head -n 1)"
    if [ -n "$mount_point" ]; then
      printf '%s\n' "$mount_point"
      return 0
    fi
  done < <(find "$usb_path" -type d -path '*/block/*' -printf '%f\n')

  echo "Mounted drive not found for $serial" >&2
  return 1
}

MODULE_A_MOUNT="$(module_mount_by_serial "$MODULE_A_SERIAL")" || exit 1
MODULE_B_MOUNT="$(module_mount_by_serial "$MODULE_B_SERIAL")" || exit 1
[ "$MODULE_A_MOUNT" != "$MODULE_B_MOUNT" ] || { echo "Module A and Module B resolve to the same drive" >&2; exit 1; }

# Write a marker file to each identified drive
printf 'Module %s\n' "$MODULE_A_SERIAL" > "$MODULE_A_MOUNT/module-$MODULE_A_SERIAL.txt"
printf 'Module %s\n' "$MODULE_B_SERIAL" > "$MODULE_B_MOUNT/module-$MODULE_B_SERIAL.txt"

This resolver uses Linux sysfs and findmnt. Confirm that both marker files appear on the expected drives.

macOS

Use uhubctl to verify each module by serial. Keep the module-to-volume mapping in your setup configuration, then write one marker file to each verified mounted path.

# Record module serials with attached drives.
# Write a distinct marker file to verify each mapping.
# No power cycle required.
MODULE_A_SERIAL="123456"
MODULE_B_SERIAL="123457"

# Verify that both modules are present
UHUBCTL_OUTPUT="$(sudo uhubctl)"
printf '%s\n' "$UHUBCTL_OUTPUT"
printf '%s\n' "$UHUBCTL_OUTPUT" | grep -F " $MODULE_A_SERIAL," >/dev/null || { echo "Module A not found: $MODULE_A_SERIAL" >&2; exit 1; }
printf '%s\n' "$UHUBCTL_OUTPUT" | grep -F " $MODULE_B_SERIAL," >/dev/null || { echo "Module B not found: $MODULE_B_SERIAL" >&2; exit 1; }

# Map each module serial to its mounted volume
mount_for_module() {
  case "$1" in
    123456) printf '%s\n' "/Volumes/Source Drive" ;;
    123457) printf '%s\n' "/Volumes/Destination Drive" ;;
    *) echo "Module serial not mapped: $1" >&2; return 1 ;;
  esac
}

MODULE_A_MOUNT="$(mount_for_module "$MODULE_A_SERIAL")" || exit 1
MODULE_B_MOUNT="$(mount_for_module "$MODULE_B_SERIAL")" || exit 1
[ -d "$MODULE_A_MOUNT" ] || { echo "Module A volume not found: $MODULE_A_MOUNT" >&2; exit 1; }
[ -d "$MODULE_B_MOUNT" ] || { echo "Module B volume not found: $MODULE_B_MOUNT" >&2; exit 1; }
[ "$MODULE_A_MOUNT" != "$MODULE_B_MOUNT" ] || { echo "Module A and Module B resolve to the same drive" >&2; exit 1; }

printf 'Module %s\n' "$MODULE_A_SERIAL" > "$MODULE_A_MOUNT/module-$MODULE_A_SERIAL.txt"
printf 'Module %s\n' "$MODULE_B_SERIAL" > "$MODULE_B_MOUNT/module-$MODULE_B_SERIAL.txt"

Use diskutil list to inspect mounted volumes. The mapping keeps the module serial as the stable key; confirm that both marker files appear on the expected drives.

Windows

On Windows, vhfilter.exe --list-hubs exposes each module's DevicePath. The example below resolves both modules by serial, follows the Windows device tree to a mounted volume, and writes one marker file to each drive.

# Run from the folder containing vhfilter.exe
# Record module serials with attached drives.
# Write a distinct marker file to verify each mapping.
# No power cycle required.
$moduleASerial = "123456"
$moduleBSerial = "123457"
$hubLines = .\vhfilter.exe --list-hubs

function Get-ModuleDevicePath([string]$serial) {
  $line = $hubLines | Select-String -SimpleMatch $serial | Select-Object -First 1
  if (-not $line -or $line.Line -notmatch '(USB\\VID_1A86&PID_8094\\[^\s]+)') {
    throw "Module serial not found: $serial"
  }
  $Matches[1]
}

function Get-ModuleVolume([string]$serial) {
  $moduleId = Get-ModuleDevicePath $serial
  foreach ($device in Get-PnpDevice -PresentOnly) {
    $currentId = $device.InstanceId
    while ($currentId) {
      $parentId = (Get-PnpDeviceProperty -InstanceId $currentId -KeyName 'DEVPKEY_Device_Parent' -ErrorAction SilentlyContinue).Data
      if (-not $parentId) { break }
      if ($parentId -ieq $moduleId) {
        $disks = @(Get-CimInstance Win32_DiskDrive | Where-Object { $_.PNPDeviceID -ieq $device.InstanceId })
        foreach ($disk in $disks) {
          foreach ($partition in Get-Partition -DiskNumber $disk.Index -ErrorAction SilentlyContinue) {
            $volume = $partition | Get-Volume -ErrorAction SilentlyContinue
            if ($volume.DriveLetter) { return "$($volume.DriveLetter):" }
          }
        }
        break
      }
      $currentId = $parentId
    }
  }
  throw "Mounted drive not found for $serial"
}

$moduleA = Get-ModuleVolume $moduleASerial
$moduleB = Get-ModuleVolume $moduleBSerial
if ($moduleA -eq $moduleB) { throw "Module A and Module B resolve to the same drive" }

Set-Content -LiteralPath (Join-Path $moduleA "module-$moduleASerial.txt") -Value "Module $moduleASerial"
Set-Content -LiteralPath (Join-Path $moduleB "module-$moduleBSerial.txt") -Value "Module $moduleBSerial"

The Windows example assumes one mounted volume per drive. Confirm that both marker files appear on the expected drives.
